Golf tracers have revolutionized the way the game is watched and played. For years, viewers relied on cameramen to track the golf ball in flight, but now, technology like Toptracer and Protracer has taken over. These systems use stationary cameras with CMOS sensors to track the entire flight of a golf ball and then add a trace graphic to the screen. This data can also be used to provide real-time analytics like ball speed, apex, curve, and carry. This seemingly simple concept has transformed the golf viewing experience, and its use has extended to golf ranges and tournaments.
| Characteristics | Values |
|---|---|
| Technology Used | Doppler radar, CMOS sensors, strategically-placed cameras |
| Camera Position | Stationary, fixed behind the golfer |
| Camera Movement | Camera can be moved to provide graphics across the course |
| Camera Height | Tower or boom camera, 20 feet above the golfer |
| Camera Angle | Directly behind the golfer |
| Data Analysis | Track and analyze the movement of the ball, relay data to a computer |
| On-Screen Graphics | Add a trace graphic to the screen, show ball speed, apex, curve, carry, etc. |
Explore related products
What You'll Learn
How golf tracers work with stationary cameras
Golf tracers have transformed the viewing experience for fans and players alike. They have also helped players gain insights into their shots. The technology behind golf tracers has been evolving since the 1950s, when the only way to view a golf shot was via the cameras themselves.
Today, Toptracer is the most used ball-tracer in golf. It uses CMOS image sensors to capture objects, specifically a golf ball in flight, and convert the multiple video angles of the struck ball to extrapolate the (nearly) exact flight of the ball. Toptracer uses a special camera to track the entire flight of a golf ball and then adds a trace graphic to the screen. This seemingly simple concept—being able to see the path of the golf ball—has forever transformed the golf viewing experience.
Toptracer's technology helps players gain real insights into every shot they take. This technology (or similar equivalents) is utilized in golf simulators and launch monitors as well. TrackMan, for example, uses radars that read the frequency of the microwaves that are reflected off the golf club and ball. This data is recorded and converted into numerous parameters.
Before Toptracer, the only way to track a golf ball was via the skill of the camera operators and the editing of the event shooting director. Stationary cameras containing sensors are used to track the movement of the ball and convert it into a graphic for television. Gyro-stabilized cameras are often used to make it easier to smoothly track the golf ball on its flight path.
There are also other golf ball-tracing apps like Shot Tracer, which is the first ball flight-tracking app for smartphones. It offers ball flight tracking, swing and putt tracing, and 3D map overlays.
