Replacing the wiper blades on your Volkswagen Golf MK5 is a straightforward task that can be done at home with a few tools. Wiper blades should be replaced periodically as they are essential for maintaining good visibility while driving in inclement weather. This guide will cover the steps to replace the front wiper blades, which is recommended to be done in pairs to ensure uniform cleaning of the windshield. It is also important to note that you should not touch the wiper blade at the working rubber edge to prevent damage to the graphite coating.
How to change MK5 Golf wipers
| Characteristics | Values |
|---|---|
| When to change wipers | When they are badly worn, or when the motor starts acting up or working intermittently |
| Tools | Flathead screwdriver, grease pencil or masking tape |
| Step 1 | Make sure the wipers are in the "park" position. To do this, turn the wipers on and off so they stop level down at the bottom of the windshield. |
| Step 2 | Mark the wipers in this position with tape or a grease pencil. |
| Step 3 | Remove the protective cap using a small flathead screwdriver. |
| Step 4 | Separate and remove the wiring harness from the wiper motor. |
| Step 5 | Remove the two T30 Torx screws that hold the assembly in place from the rubber grommets. |
| Step 6 | Remove the bulkhead protection plate by unscrewing the two 10mm fasteners. |
| Step 7 | Unclip the wiring harness and pull the bulkhead piece and rubber seal from the vehicle. |
| Step 8 | Swing the assembly forward and out. |
| Step 9 | Use a large flathead screwdriver to pry the linkage rod off the assembly crank. |
| Step 10 | Prepare the new windscreen wipers. |
| Step 11 | Pull the wiper arm away from the glass surface until it stops. |
| Step 12 | Press the clip and use a flat screwdriver to remove the blade from the wiper arm. |
| Step 13 | Turn the ignition on again (without starting the engine) and push down once on the wiper stalk and release. |
| Step 14 | Check the wipers' performance. |
Explore related products
What You'll Learn
Preparing to replace wiper blades
To prepare for replacing your wiper blades, park your Volkswagen Golf MK5 and turn on the ignition. Pull the windscreen wiper stalk to the downward position and then switch off the ignition. The wipers will now be in the upper position, also known as the service mode.
Before removing the old wiper blades, make sure you have the correct replacement blades. Wiper blades come in different types, such as the side-loading pin type, so ensure you have the right ones for your vehicle. It is recommended to replace both front wiper blades together to ensure efficient and uniform cleaning of the windshield.
Gather the necessary tools for the job. You may need a flat-head screwdriver to remove the wiper blades, as well as a new set of wiper blades. Always handle the wiper blades with care and avoid touching the working rubber edge to prevent damage to the graphite coating.
If your wiper motor is acting up or working intermittently, you may need to replace it. You can test the power and ground to the motor to see if it is receiving the signal to turn on. If the motor has failed, you will need to follow additional steps to replace it, which may include removing the bulkhead protection plate and disconnecting the wiring harness.
By preparing the necessary tools, acquiring the correct replacement blades, and understanding the procedure, you will be well-equipped to replace the wiper blades on your Volkswagen Golf MK5.
Golfer Ken Brown: Married Life Insights
You may want to see also
Explore related products
Parking the wipers
To park your wiper blades, first, switch off the ignition and remove the key from the barrel. Now, turn the ignition to position '1' without starting the engine. This will activate the accessories and allow you to operate the wipers. Engage the stalk and set the wipers in motion. When the wipers reach the midpoint on your windshield, they are in the parking position. At this point, turn the ignition back to '0' and remove the key. Your wipers should now be parked and ready for replacement.
It is important to park your wiper blades in the correct position to ensure they do not obstruct your view and to prevent any damage to the blades or windshield. When replacing the blades, it is a good opportunity to give your windshield a thorough clean, inside and out, to ensure optimal visibility. Always take care when working around your windshield, as incorrect installation or positioning of the wiper blades can lead to smearing and impaired visibility.
Remember to take your time and be gentle during the process, as forcing the wiper arms or blades can lead to damage. If you encounter resistance or the wiper arms do not move freely, re-check that you have followed all the steps correctly and that no obstruction is causing the issue. With careful attention, you can efficiently park your wiper blades and proceed to replace them.
Lydia Ko's Marriage: Is She Married?
You may want to see also
Explore related products
Removing the wiring harness
To remove the wiring harness, you must first ensure that your wipers are in the "park" position. To do this, turn the wipers on and off, and they should stop level down at the bottom of the windshield. This is the park position. If your wiper motor failed in another position, carefully move the wipers by hand down into the park position. Once you have done this, mark the wipers in this position with a grease pencil or masking tape.
Next, use a small flathead screwdriver to remove the protective cap. You should now be able to see the electrical connection. Separate and remove the wiring harness from the wiper motor. Then, use a T30 Torx screwdriver to remove the two screws that hold the assembly in place from the rubber grommets.
Now, you will need to remove the bulkhead protection plate to get the motor assembly out. It is held in place by two 10mm fasteners, one on each side. Remove these fasteners, then unclip the wiring harness and pull the bulkhead piece along with the rubber seal from the vehicle.
Finally, swing the assembly forward and out. Place the assembly on a bench and use a large flathead screwdriver to pry the linkage rod off the assembly crank.
Golf Tees: How Are They Made?
You may want to see also
Explore related products
Taking out the bulkhead protection plate
To take out the bulkhead protection plate, you will need to remove the two 10mm fasteners that hold it in place (one on each side). Once these fasteners have been removed, you can then unclip the wiring harness and pull the bulkhead piece out along with the rubber seal.
It is important to note that this step is part of a larger process for replacing the windshield wiper motor on a Volkswagen Golf GTI Mk V (2006-2009). Before removing the bulkhead protection plate, you will have already placed the wipers in the "park" position, marked this position with tape, removed the protective cap, separated the wiring harness from the wiper motor, and removed the two T30 Torx screws holding the assembly in place.
After removing the bulkhead protection plate, you will be able to swing the assembly forward and out. From there, you can place the assembly on a bench and use a large flathead screwdriver to pry the linkage rod off the assembly crank.
This process may vary slightly depending on the specific design of your Volkswagen Golf. It is always recommended to consult a professional or a detailed maintenance guide before attempting any DIY vehicle maintenance or repairs.
Golf: Avoid Slicing with Simple Tips
You may want to see also
Explore related products
Installing new wiper blades
To install new wiper blades on a Volkswagen Golf MK5, first, make sure the wipers are in the park position. You can do this by turning the wipers on and off, and they should stop level down at the bottom of the windshield. This is known as the park position. If your wiper motor failed in another position, you should be able to carefully move them by hand down into the park position.
Next, switch on the ignition and pull the windscreen wiper stalk to the downward position. Then, switch off the ignition. In the service mode, the wipers will now be in the upper position. Prepare your new windscreen wipers by pulling the wiper arm away from the glass surface until it stops. Press the clip and use a flat screwdriver to remove the blade from the wiper arm.
Now, you can install the new wiper blades. Ensure that the blade rubber strip fits tightly to the glass along the entire length. Don't touch the wiper blade at the working rubber edge to prevent damage to the graphite coating. After installation, check the wipers' performance. The blades shouldn't intersect or bump against the windshield seal.
Finally, turn the ignition on again without starting the engine. Push down once on the wiper stalk and release. The wiper blades will then return to their original position, and you have now replaced the wipers.
