Removing the seats from a Volkswagen Golf can be done in a few different ways depending on the model of the car and the specific seat in question. For example, to remove the rear seat of a Mk1 Golf, one must simply unscrew the two plastic covers at the front of the seat and the metal tab at the back, and then slide the seat forward. Removing the front seats of a Mk1 Golf is similarly straightforward, requiring the removal of a stopper nut and bolt before pulling a lever and sliding the seat back. However, removing seats from later models of the Golf, such as the Mk IV and Mk V, may involve additional steps such as disconnecting wiring harnesses and removing trim pieces.
Explore related products
What You'll Learn
Removing the rear seat
First, locate the two tabs with plastic covers at the front of the seat, where it meets the carpet. Undo the screws attaching these tabs to the car's floor, making sure to keep the plastic covers safe so they can be reused. There is also a third metal tab at the back of the seat, which is not held in with screws or bolts.
Next, gently slide the seat towards the front of the car. This will allow you to pull the third tab away from where it is anchored. With all the tabs released, you can now carefully remove the seat. Be cautious when removing the seat, especially around the seat belts.
With the rear seat removed, you will have access to the fuel sender unit, lifter pump, and seatbelt anchors. This process should take approximately 10 minutes to complete.
If you are also removing the rear seat backs, there are a few additional steps. First, remove the carpet section over the spare tire and the two foam inserts. You do not need to remove the spare tire itself. Next, use a trim removal tool to remove the trim piece over the rear seat hinge mount. With the plastic trim piece removed, you will see a single Torx screw that needs to be removed using a T30 Torx. The right-side seat back includes the upper seat belt anchor for the middle seat, so be sure to carefully manage the seat belts during this process.
Golf Teams in TGL: How Many Are There?
You may want to see also
Explore related products
Disconnecting the wiring harness
First, identify the wiring harness. It is usually located at the front of the seat and is connected to various features such as side airbags, heating, and power. The wiring harness will have a connector mount attached to it, which will remain with the seat when it is removed.
Next, carefully disconnect the wiring harness from the connector mount. This step requires precision to avoid any damage to the connectors. Make sure to follow specific instructions for your Golf 1 model, as the process may vary slightly. For example, for the Volkswagen Golf GTI Mk V, you need to open the flap in the carpet on the floor at the front left of the driver's seat to access the wiring connections.
After disconnecting the wiring harness, set it aside safely. Ensure that you do not put unnecessary strain on the wires during this process, as it may damage the wiring or the connectors.
Once the wiring harness is disconnected, you can proceed with the rest of the seat removal process. This may involve sliding the seat back or forward, removing bolts or nuts, and lifting the seat out of the vehicle, depending on your specific Golf 1 model.
Remember to handle the wiring harness with care throughout the process. When reinstalling the seats, ensure that the wiring harness is correctly reconnected and secured before finalising the installation.
Golf's Olympic Status: A Sport's Future
You may want to see also
Explore related products
Removing the seat covers
To remove the seat covers of a Volkswagen Golf, you will need to first remove the seats themselves. This process is relatively straightforward and can be done in about 15 minutes.
For the front seats, begin by sliding the seat all the way back. Remove the two nuts on the bracket at the lower front of the seat. Next, slide the seat all the way forward and remove the trim cap on the two trim pieces that cover the seat rails. After removing the trim cap, take out the Philips head screw below. Now, slide the trim piece up and back. Please note that the trim caps are very difficult to remove without marring, so if you want your car to look pristine, you should be prepared to replace them.
Slide the seat to the rear until the rollers clear the seat rails. You can now tilt the seat back to access the underside. Depending on your seat's features, you may need to disconnect the wiring harness. Some seats include side airbags, heat, and power. Disconnect the harness clip from the connector mount on the bottom of the seat. The connector mount will stay with the seat when you remove it.
Now, you can safely remove the seat from the car. To remove the rear seats, follow a similar process, but note that they come out in two sections: the lower and upper parts. Use the pull strap to pull the seat cushion forward and up; it will pivot on the mounting rods.
For the rear armrest, fold it up into the stowed position. Use a T30 Torx to remove the two Torx screws, then open the armrest. The complete unit with the mounting bracket will slide down and out from between the seats. There are four plastic clips protecting the child seat anchors. Unclip and remove these plastic covers. There are also two retaining clips at the forward edge of the rear seat bench. Pull the bench straight up to release these.
Now, lift the front of the seat upwards, then push the seat back and remove it. Be careful when removing the bench from around the seat belts. To remove the rear seat backs, first, remove the carpet section over the spare tire and the two foam inserts. Use a trim removal tool to remove the trim piece over the rear seat hinge mount. With the plastic trim piece gone, use a T30 Torx to remove the single Torx screw.
Remove the metal cover over the hinge mount. The two rear seat backs sit in this hinge mount. You can now pivot the seat back out from the hinge mount and slide it towards the center of the car to free it from the post on the opposite side. The seat back is now free and can be removed from the car.
Now that you have removed the seats, you can focus on removing the seat covers. This process may vary depending on the specific model and design of your Golf 1 seats. However, here are some general steps and tips to guide you through the process:
- Remove all the trim and clips or wire rings that secure the cover and cushion of the seat.
- Some seats may have additional attachments or mechanisms that need to be released or detached.
- Gently pull or lift the seat cover away from the seat once all the attachments have been released.
- Be careful not to use excessive force, as you do not want to damage the seat cover or any underlying components.
- If necessary, use a trim removal tool or a flat-head screwdriver to carefully pry or leverage the cover away from the seat, starting from the edges and working your way in.
- Once the cover is removed, you will have access to the foam and other underlying components for cleaning, replacement, or repair.
Remember to take your time and work carefully to avoid any damage to your Golf 1's seats or interior. If you encounter any difficulties or complexities specific to your model, consult a trusted mechanic or a Volkswagen Golf forum for more specialized advice.
Golf App on Gear S3: What You Need to Know
You may want to see also
Explore related products
Removing the front seats
Step 1: Prepare the Workspace
Before beginning, ensure you have the necessary tools, which include a Phillips head screwdriver, a ratchet, a 13mm socket, and a pocket screwdriver. Additionally, having a trim removal tool and a flathead screwdriver can be useful for certain models. Clear the workspace around the seat to allow easy access and movement.
Step 2: Move the Seat
Slide the seat all the way forward to gain access to the mounting points and fasteners. Depending on the model, there may be bolts or Torx screws securing the seat in place. For Mk1 Golf, there is a bolt held in place with an acorn nut at the front and centre of each seat.
Step 3: Remove Fasteners and Covers
Remove the fasteners that secure the seat in place. For bolts, use a socket or ratchet to loosen and remove them. For Torx screws, use the appropriate screwdriver. Be cautious when removing fasteners, as some may have plastic covers that need to be retained. Additionally, remove any plastic trim covers that provide access to the fasteners and screws.
Step 4: Disconnect Wiring and Components
Depending on the options equipped on your seat, there may be wiring harnesses and connectors that need to be disconnected. This includes wiring for features such as side airbags, heating, and power adjustments. Carefully detach any wiring harnesses and connectors, ensuring not to damage any components.
Step 5: Slide and Tilt the Seat
Once all fasteners and wiring have been removed, slide the seat all the way back. You may need to gently tilt the seat backward to release it from the tracks. Be cautious not to catch the seatbelt or damage any plastic trim during this process.
Step 6: Remove the Seat
With the seat fully tilted and slid back, carefully lift the seat and remove it from the vehicle. Pay attention to the positioning of the seat in relation to the door openings to facilitate a smooth removal.
Reinstallation:
To reinstall the seats, follow these steps in reverse, ensuring that all fasteners and wiring are securely connected.
Galaxy Golf: Scam or Legit?
You may want to see also
Explore related products
Removing the rear armrest
First, it's important to note that the procedure may vary slightly depending on the model and year of your Golf 1. In this guide, we will focus on the process for the Volkswagen Golf GTI Mk V model years 2006-2009, as per the available sources.
To begin removing the rear armrest, you will need to open the cup holder and remove the two T20 Torx screws located inside. Remember to close the cup holder before proceeding to the next steps. Next, use a trim removal tool or your fingers to gently separate the plastic surround from the base on both sides of the armrest. Be careful not to damage the plastic pieces during this step.
Once the plastic surround is removed, you can pivot the armrest piece up from the bottom and then lift it upward from the hinge on the top to detach it. At this point, the armrest should be removed, and you can now access the parking brake cable and handle assembly if necessary.
It is recommended to watch online videos for a better understanding of the process, especially if you are unsure about any steps. Additionally, some sources suggest that removing the armrest is easier when it is off the car, but it is still doable with the armrest on. Just be cautious not to drop any screws or small parts inside the car.
