Removing seats from a Volkswagen Golf GTI Mk IV (1999-2005) is a relatively straightforward process. The procedure involves sliding the seat back and forth to access bolts, screws, and wiring harnesses that need to be removed. For the rear seats, there is a pull strap mechanism that releases the seat cushion, allowing access to the mounting rods, which can then be removed. The front seats of the Golf, unlike the Jetta, use bolts rather than Torx screws. It is important to be cautious when removing seats to avoid damaging the plastic trim or other components.
Explore related products
What You'll Learn
Slide the seat back to reveal bolts or screws
To remove the seats from a Volkswagen Golf GTI Mk IV (1999-2005), begin by sliding the seat all the way back. This will reveal bolts or screws at the front of the seat bracket. If you have a Golf, there should be bolts. In contrast, a Jetta will have a Torx screw.
Once you have located the bolts or screws, remove them. Then, slide the seat forward to reveal the trim cap on the two trim pieces that cover the seat rails. Remove the trim cap and the Philips head screw below. Next, slide the trim piece up and back. The left side trim piece can be removed to expose the seat rail. Be careful when removing the trim caps, as they are difficult to remove without causing damage. If you want your car to look pristine, you may need to replace them.
Now, slide the seat all the way back again and tilt it backwards. This will allow the wheels to come off the track, enabling you to pull the seat out.
Golf Locker: Trustworthy Golfing Companion?
You may want to see also
Explore related products
Remove the plastic trim covers
To remove the plastic trim covers from your MK4 Golf, you will need a flat-head screwdriver and a plastic prying tool. Start by prying up the front edge of the plastic trim cover, which is located on the bottom of the seat, using your flat-head screwdriver. Be careful and use gentle force to avoid breaking the plastic. Once you have pried it up enough to get a good grip, simply pull the cover towards you and lift it over the seat frame to remove it completely. For the side plastic trim covers, begin by prying up the rear edge of the cover using the same technique. Then, lift and remove it. Some MK4 Golf models may have additional plastic trim pieces, such as a small cover over the seat height adjustment lever. To remove this, gently pry it up with your screwdriver and then lift it away. The plastic trim covers should now be completely removed, exposing the bolts that secure the seat to the vehicle's floor. With these trim pieces removed, you can now access the bolts and proceed to the next step of completely removing the seat. It is important to keep the plastic trim covers safe as you will need to reinstall them when putting the seats back in.
Golf Greenies: What Are They?
You may want to see also
Explore related products
Disconnect electrical connectors
Disconnecting the electrical connectors is a crucial step in removing the seats from your MK4 Golf. Here is a detailed guide to help you through the process:
First, slide the seat all the way back. This will give you access to the electrical components underneath the seat. You may need to remove some bolts or screws to fully access the electrical connectors. Depending on your specific seat configuration, there may be features such as side airbags, seat heaters, or power connectors that need to be disconnected. Identify these connectors and make sure to disconnect them carefully.
For example, if your seat has a side airbag, you will need to locate the wiring harness and disconnect it. The wiring harness is typically secured with a harness clip that needs to be released from the connector mount on the bottom of the seat. This connector mount will remain with the seat when you remove it. Similarly, if your seat has power connectors, such as for seat adjustment or heating, make sure to locate and disconnect these as well.
In addition, the seat belt buckle connector is another important electrical connector to address. Ensure that you disconnect it before attempting to remove the seat. By doing so, you prevent any accidental activation of the seat belt during the removal process.
Once all the electrical connectors have been safely disconnected, you can proceed to the next step of removing the seat. It is important to be cautious and careful throughout the process to avoid damaging any electrical components or connectors. If you are unsure about any specific connectors, it is always best to consult a professional or refer to a detailed MK4 Golf seat removal guide.
By following these instructions, you can confidently disconnect the electrical connectors and continue with the removal of the MK4 Golf seats. Remember to take your time and carefully address each connector to ensure a smooth and safe process.
Golfer Ken Brown: Married Life Insights
You may want to see also
Explore related products
$74.99
Remove the rear seat in two sections
To remove the rear seat in two sections, first, pull the seat cushion forward and up using the pull strap. The cushion will pivot on the mounting rods. Flip the seat all the way forward and remove the rods by pushing them towards each other. You may need a large screwdriver or a hammer to get the first rod out, and then you can wiggle the second one free.
Next, locate the two handles on the upper seat section and pull the seat back forward. With the seat folded down, you will see the two pivot points. Release the outside point first, then pull the seat back out of the inside pivot point.
Now, you have successfully removed the rear seat in two sections. You can now replace or repair the seat as needed. Remember to exercise caution and avoid damaging any surrounding components during this process.
It is important to consult a professional mechanic or a qualified technician if you are unsure about any steps or encounter any unexpected issues during the removal process.
Golf's Greatest: Who's the GOAT?
You may want to see also
Explore related products
Remove the front seat by tilting it backwards
To remove the front seat of a Volkswagen Golf GTI Mk IV, begin by sliding the seat all the way back. Remove the two 13mm nuts or bolts on the bracket at the lower front of the seat. If you have a Jetta, there will be a Torx screw instead. Then, slide the seat all the way forward. You will now need to remove the trim cap on the two trim pieces that cover the seat rails. After removing the trim cap, remove the Philips head screw beneath it. Next, slide the trim piece up and back, being careful not to break the tab at the front.
Now, slide the seat all the way back again and tilt it backward. This will allow the wheels to get off the track so you can pull the seat out. Before removing the seat, check for any electrical connectors and disconnect them if present. This includes wiring for features such as seat heaters, side airbags, and power. Once all connectors have been disconnected, you can carefully lift the seat out of the car.
