Reshafting a golf putter can be a simple process, but it is important to know when and how to do it. The shaft of a golf club can have a significant impact on performance, transferring power from the player to the clubhead and ultimately to the ball. While reshafting can be done at home, it is recommended to consult a professional for the best results. This guide will cover the steps to reshaft a golf putter, including the tools and materials needed, and the process of removing the old shaft and installing the new one.
Characteristics and Values Table for Reshafting a Golf Putter
| Characteristics | Values |
|---|---|
| When to reshaft | When the shaft breaks, when ball flight changes dramatically, or when swing mechanics change |
| Tools | Shaft Vise Clamp, torch or heat gun, Hyde Knife, wire brush, paper towel, Shaft Identification Gauge, drill, sandpaper, vice, grip tape, mineral spirits, shaft epoxy, chopstick or Popsicle stick, shafting beads |
| Steps | 1. Clamp shaft into vise. 2. Warm ferrule slightly. 3. Cut ferrule off shaft. 4. Heat hosel to remove steel shafts from clubheads. 5. Remove excess epoxy from hosel. 6. Apply Blue Away to remove heat marks. 7. Measure shaft tip with Shaft Identification Gauge. 8. Select shaft using Shaft Playability Factor. 9. Heat up glue inside hosel with heat gun or blowtorch. 10. Pull shaft out of head. 11. Remove glue inside hosel with drill or sandpaper. 12. Insert new shaft and mark where it meets hosel. 13. Remove shaft and rough it up with sandpaper. 14. Install new shaft with epoxy |
Explore related products
What You'll Learn
Removing the old shaft
Start by clamping the shaft into a vise, using a shaft vise clamp to secure it in place. This step is crucial to ensuring stability and safety during the removal process. Next, apply heat to the hosel—the part of the clubhead where the shaft is inserted. Use a heat gun or blowtorch to warm the hosel for about 30 seconds. Be cautious not to overheat, as this can damage the clubhead. The goal is to heat up the glue inside the hosel, softening it enough to remove the shaft.
After heating, carefully pull the shaft out of the head. It will be warm, so protect your hands with gloves. Once the shaft is removed, the remaining glue inside the hosel needs to be addressed. This can be done by using a small drill bit at a slow speed to disturb the glue without actually drilling into the hosel. Alternatively, a roll of sandpaper can be used to rub against the edge of the hosel, dislodging the glue.
At this point, the old shaft has been successfully removed, and you can move on to inserting the new shaft. However, it is important to clean the hosel and prepare it for the new shaft. Use a wire brush to remove any excess epoxy or glue residue from the inside of the hosel. This step is crucial for achieving a strong bond when installing the new shaft. After cleaning, the hosel should be allowed to cool before applying a heat mark removal agent, such as Blue Away, to remove any heat marks created during the heating process.
The Art of Striping Golf Grass
You may want to see also
Explore related products
Using a heat gun or blowtorch
Step 1: Applying Heat
- Using a heat gun or blowtorch, apply heat to the hosel for a few seconds on each side. It is important to note that you are only aiming to soften the glue, not melt the hosel.
- If using a heat gun, hold the nozzle approximately 3 to 4 inches away from the hosel and heat on a high-temperature setting for about 1 minute.
Step 2: Removing the Putter Head
- After applying heat, twist off the putter head to separate it from the shaft.
- If the head seems determined to stay on the shaft, apply heat for another 15-30 seconds and then try again.
Step 3: Cleaning the Hosel
- Once the putter head is removed, use a brush, small drill bit, or sandpaper to remove any excess glue or residue from the hosel.
- This step is important as it ensures a smooth installation process for the new shaft.
Step 4: Preparing the New Shaft
- Use sandpaper to roughen the tip of the new shaft, focusing only on the area that will be concealed by the hosel.
- This step helps to create a better bond between the new shaft and the putter head.
It is important to wear protective gear, such as safety glasses and leather gloves, when using a heat gun or blowtorch to reshaft a golf putter. Additionally, be cautious not to overheat the hosel, as it can strip or change the colour of the paint.
Golf Mornings: How Long Do They Last?
You may want to see also
Explore related products
Removing excess glue
Firstly, it is important to warm up the clubhead. This can be done using a heat gun or a blow torch. Be cautious and ensure that you only heat the glue inside the hosel, without melting any other parts of the club. A couple of seconds should be sufficient to heat and soften the glue.
Once the glue is heated, carefully remove the old shaft. The hosel will be warm, so be careful not to burn yourself. Now, the excess glue inside the hosel needs to be disturbed and removed. There are a few methods you can use for this process. One method is to use a small drill bit at a slow speed. Carefully rub the edge of the hosel with the drill bit to dislodge the glue without drilling into the club. Alternatively, you can use a roll of sandpaper to rub and dislodge the glue. Be gentle and ensure you do not damage the hosel.
If there is dried epoxy on the clubhead, you can use a wire brush to remove it. The warmth of the clubhead will make this process easier. You can also apply a product like Blue Away to a paper towel and rub the hosel to remove any heat marks created during the heating process.
By following these steps, you will effectively remove excess glue and prepare the clubhead for the new shaft. Remember to work carefully and patiently, ensuring a clean and smooth surface for the next steps of the reshafting process.
Understanding Golf's HCP System: How It Works
You may want to see also
Explore related products
Inserting the new shaft
Once the shaft and hosel are prepared, you can apply the epoxy. Use shaft epoxy to bond the shaft to the hosel. Ensure that the epoxy is evenly applied and that there are no gaps. Insert the shaft into the hosel and align the marks you made previously. Hold the shaft in place until the epoxy sets. You can use a chopstick or Popsicle stick to remove any excess epoxy.
Allow the epoxy to dry completely before proceeding. The drying time will vary depending on the type of epoxy used and the environmental conditions. Once the epoxy is dry, you can clean up any remaining epoxy residue on the hosel with a paper towel and Blue Away. This will ensure that your new shaft is free of any heat marks or residue.
Finally, you can install the new grip. Unfortunately, you cannot reuse a putter grip, so you will need to purchase a new one. Follow the manufacturer's instructions for installing the grip, as different grips may have varying methods. And that's it! You've successfully reshafted your putter and can now enjoy improved performance and consistency with your shots.
A Fun Round of Crazy Golf: How Long Does It Take?
You may want to see also
Explore related products
Using epoxy to install the shaft
First, you need to get the old shaft out. You can use a heat gun or a blowtorch to heat up the glue inside the hosel. Be careful not to melt the hosel – a couple of seconds will do the job. Once it's warm, carefully pull the shaft out of the head. Next, you need to get rid of the glue inside the hosel to promote a great bond for your new shaft. You can use a small drill bit at a slow speed to disturb the glue, or simply dislodge it with a roll of sandpaper.
Now you're ready to insert the new shaft. First, insert it all the way in, then make a mark where it meets the hosel. Remove the shaft and use some sandpaper to rough it up. Finally, apply the epoxy to the shaft and insert it into the hosel, being careful not to get any epoxy on the outside. Leave the putter to dry, and you're done!
It's important to note that some older heads may be pinned in place. If in doubt, seek expert advice.
Golf Gloves: Is Nike Still in the Game?
You may want to see also
Frequently asked questions
The shaft transfers power from you to the clubhead and ultimately to the ball. The right shaft can help you become more consistent with your shots. You may need to reshaft your putter if your ball flight changes dramatically, or if your swing mechanics change.
You will need a heat gun or blowtorch, a small drill bit, sandpaper, shaft epoxy, grip tape, a new grip, and a vice.
First, heat up the hosel to warm the glue and remove the old shaft. Next, remove the glue inside the hosel with a drill bit or sandpaper. Then, insert the new shaft, mark where it meets the hosel, and remove the shaft. Finally, rough up the shaft with sandpaper, apply epoxy, and insert the shaft into the hosel.
