The Pitch Circle Diameter (PCD) of a Volkswagen Golf refers to the diameter of the circle that passes through the centre of all the wheel bolts. The PCD for the Mk4 Golf is 5x100, meaning that the wheel bolts are set in a circle with a 100mm diameter. This is different from later models of the Golf, which have a PCD of 112x5.
| Characteristics | Values |
|---|---|
| Pitch Circle Diameter (PCD) | 5x100 |
| Years | 1997-2006 |
| Diesel Engine | 1.9 SDI I4 67hp, 1.9 TDI I4 89hp, 1.9 TDI I4 109hp, 1.9TDi I4 90hp, 1.9TDi I4 148hp |
| Petrol Engine | 1.4i I4 74hp, 1.6i I4 101hp, 1.6i I4 99hp, 1.6i (GF-1JAEH) I4 99hp, 1.6i (GF-1JAVU) I4 101hp, 1.8T I4 148hp, 1.8T (GF-1JAUM) I4 148hp, 1.8T GTI I4 177hp, 1.8i I4 123hp, 2.0i I4 115hp, 2.0i I4 113hp, 2.0i (GF-1JAPK) I4 114hp, 2.3i V5 148hp, 2.3i V5 168hp, 2.8i V6 201hp |
Explore related products
What You'll Learn
The Mk4 Golf's PCD is 5x100
The Mk4 Golf has a PCD of 5x100. This means that the diameter of the circle that passes through the centre of all the studs, wheel bolts, or wheel rim holes is 100mm, and there are 5 studs, bolts, or holes. This PCD is specific to the Mk4 Golf platform, which includes the Mk4 Golf, as well as the same-generation Leon and Octavia.
The Mk4 Golf's PCD is different from newer VAG cars, which have a PCD of 112x5. This means that newer VAG car wheels will not fit on the Mk4 Golf. However, earlier Cupra wheels will fit the Mk4 Golf, as they have the same PCD.
It is important to note that when upgrading or changing wheels, it is crucial to consider not only the PCD but also the offset and the centre bore size to ensure proper fitment and compatibility. The offset refers to the distance from the centre line of the wheel to the wheel's mounting face, and the centre bore is the size of the hole in the centre of the wheel.
Additionally, when upgrading wheels, it is important to consider the maximum wheel size that can be fitted without compromising the ride quality and handling of the vehicle. While larger wheels may be aesthetically pleasing, they can impact the ride comfort and handling characteristics of the car. It is recommended to refer to the vehicle's specifications and seek professional advice when making wheel upgrades to ensure safety and compatibility.
Golf Girlfriend Guide: How to Be a Pro
You may want to see also
Explore related products
Audi A3/A4 wheels won't fit the Mk4 Golf
The Mk4 Golf has a PCD of 5x100, which means that the studs on the car are set in a circle with a 100mm diameter. Newer Audi A3 and A4 wheels have a PCD of 5x112, which means the studs are arranged in a circle with a 112mm diameter. As the PCD of the Mk4 Golf and the Audi A3/A4 wheels don't match, it is not generally possible to fit Audi A3/A4 wheels onto a Mk4 Golf.
The PCD of a car is an important factor in determining whether a particular set of wheels will fit. PCD stands for Pitch Circle Diameter, and it refers to the diameter of the circle that passes through the centre of the wheel's bolt holes. The PCD is usually expressed as a series of numbers, such as 5x100 or 5x112. The first number indicates the number of bolt holes in the wheel, and the second number indicates the diameter of the circle that passes through the centre of these bolt holes.
It is important to match the PCD of the wheels to the PCD of the car when choosing aftermarket wheels. If the PCD of the wheels is smaller than the PCD of the car, the wheels will not fit onto the car's hubs, as the studs will not line up with the bolt holes. If the PCD of the wheels is larger than the PCD of the car, the wheels may fit onto the studs, but the bolt holes will not line up with the studs, and the wheel will not be securely attached to the car.
While it is generally not possible to fit Audi A3/A4 wheels onto a Mk4 Golf due to the difference in PCD, there may be some exceptions. For example, some older models of the Audi A3 may have a PCD of 5x100, which would match the PCD of the Mk4 Golf. Additionally, there may be wheel spacers or adapters available that would allow Audi A3/A4 wheels to be fitted to a Mk4 Golf, but these would need to be specifically designed for this purpose and safely installed.
How Often Do Golf Courses Move Pin Locations?
You may want to see also
Explore related products
Seat Cupra wheels will fit the Mk4 Golf
The Mk4 Golf has a PCD of 5x100, which means the wheel has five wheel nuts set in a 100mm diameter circle. This is different from more modern VAG cars, which have a PCD of 112x5 and will not fit the Mk4 Golf.
Regarding Seat Cupra wheels, it depends on the specific model and year of the Cupra wheels in question. Earlier Cupra wheels will fit the Mk4 Golf, as they have the same PCD of 5x100. However, later Cupra wheels may not fit, as Seat transitioned to a PCD of 112x5 around the same time as VW.
Some sources specifically mention the Seat Leon Cupra R wheels, which are 18-inch alloys with a PCD of 5x100. These wheels are confirmed to fit the Mk4 Golf without any arch issues. There are also reports of people successfully fitting 17-inch Seat Cupra wheels to the Mk4 Golf, although in some cases, minor modifications or additional parts may be required.
In summary, earlier Seat Cupra wheels with a PCD of 5x100 will fit the Mk4 Golf. Later Cupra wheels with a PCD of 112x5 will not be compatible. Always ensure that the offset is also compatible and that you follow the correct safety procedures when performing any modifications.
Golf Payout Places: How Many Winners Get Paid?
You may want to see also
Mk4 Golf wheels are the last Golf wheels with a 5x100 PCD
The Volkswagen Golf Mk4/A4 (1J) was manufactured between 1997 and 2006. The Pitch Circle Diameter (PCD) of a wheel refers to the diameter of the circle passing through the centre of all the studs, wheel bolts or wheel rim holes. The Mk4 Golf wheels have a 5x100 PCD, meaning that there are five wheel nuts set in a 100mm diameter circle.
The Mk4 Golf is the last Golf model with a 5x100 PCD. Later Volkswagen Golf models, such as the Mk5 and newer versions, have a different PCD of 112x5. This change in PCD means that the wheels from later Golf models will not fit on the Mk4 without adaptors or modifications.
It is important to note that the PCD is just one factor to consider when choosing wheels for a vehicle. Other specifications, such as the offset, centre bore, and tyre size, also play a crucial role in ensuring the wheels fit properly and function correctly. The offset, for example, refers to the distance in millimetres from the centre line of the wheel to the wheel's mounting face, and can be neutral, positive, or negative depending on the position of the mounting face relative to the centre line.
When upgrading or modifying wheels, it is always recommended to consult with professionals or experts to ensure compatibility and adhere to safety standards.
Golf R's Turbocharged Performance: What's Under the Hood?
You may want to see also
You can use adaptors to fit 5x112 rims on a Mk4 Golf
The Mk4 Golf has a PCD of 5x100, meaning the rims are set in a 100mm diameter circle. This is different from the PCD of 5x112 rims, which are found on some Audi and VW models. While the Mk4 Golf's PCD is 5x100, it is possible to use adaptors to fit 5x112 rims on this vehicle.
Some Mk4 Golf owners have successfully fitted 5x112 rims using adaptors. The process typically involves machining the hub carriers and changing the standard offset to accommodate the new rim size. It is important to note that this modification may require custom wheels, as the new offset can be too far out for standard Audi or VW wheels.
When considering using adaptors, it is essential to take into account the wheel offset, also known as ET, which can vary even among rims with the same PCD. The offset affects how far the rim sits from the vehicle's hub, impacting factors such as handling and tyre clearance.
The use of adaptors may also affect the overall width of the vehicle, causing the wheels to stick out further than with direct-fitment rims. This may require additional modifications, such as rolling and flaring the arches, to ensure proper clearance and avoid rubbing issues.
While it is possible to use adaptors to fit 5x112 rims on a Mk4 Golf, it is important to carefully consider all aspects of the modification, including wheel offset, spacer thickness, and potential changes to the vehicle's width and appearance. It is always recommended to consult with professionals or experienced enthusiasts before making significant vehicle modifications.
Takomo Golf: Where is it Based?
You may want to see also
Frequently asked questions
The Pitch Circle Diameter (PCD) of a MK4 Golf is 5x100.
PCD stands for Pitch Circle Diameter.
The Pitch Circle Diameter is the diameter of the circle that passes through the centre of all the wheel bolts.
Yes, wheels from other cars in the same generation will fit, including the Leon and Octavia. However, newer models have a different PCD, so their wheels won't fit.
