The Volkswagen Golf is a popular car model that has been in production since 1974. One issue that some owners of the MK4 Golf have faced is a faulty panic alarm that goes off for no apparent reason. This can be caused by a number of factors, including a faulty driver's door lock actuator or chafed and corroded wires. While some owners have tried to fix these issues, others have sought to disable their MK4 Golf's alarm entirely. One method involves removing the blue 16-pin plug from the comfort module, which can be found by removing the trim surround panel for the fuse block. Another method involves removing the central locking fuse from the fuse box, which is located on the right-hand side of the dashboard.
| Characteristics | Values |
|---|---|
| Location of alarm | Under the dash to the right of the steering column above the relay plate |
| Where to find the fuses | On top of the relay plate |
| Fuses to remove | S144 and S111 (both 15 amp fuses) |
| Effect of removing fuses | Shuts down the alarm, central locking, and alarm horn |
| Alternative method | Remove the blue 16-pin plug from the comfort module |
| Effect of alternative method | Disables the factory alarm but retains central locking and car starting capabilities; however, electric windows and the dome light are disabled |
| Cause of alarm randomly going off | Possibly due to a faulty driver's door lock actuator or chafed and corroded wires |
Explore related products
What You'll Learn
Removing the trim surround panel
With the fuse block moved, you will now have access to the "comfort module". This is a black plastic box with two connectors facing the back of the car. The next step is to unplug the connector nearest to you, which will be the smaller of the two. There are retention latches on the top and bottom of the plug that need to be squeezed together to release it.
At this point, the alarm's ability to honk the horn, flash the lights, and lock out the starter will be eliminated. However, the electric locks will still work, and the alarm can still be set. If desired, you can remove the screw in the holding bracket to take out and inspect the module, but this is not necessary to disable the alarm.
Swearing in Golf: Penalty or Not?
You may want to see also
Explore related products
Unplugging the connector
Disabling the alarm on a Golf MK4 requires access to the fuse block. This can be achieved by removing the trim surround panel, which is a snap-on/off piece. Once the panel is removed, the two screws holding the fuse block in place can be unscrewed, and the block can be pushed in and manoeuvred out of the way. At this point, you will see a black plastic box ("comfort module") with two connectors facing the back of the car.
The next step is to unplug the connector to disable the alarm. The connector you want to unplug is the smaller of the two, and it is the nearest one to you. There are retention latches on the top and bottom of the plug that need to be squeezed together to release it.
It is worth noting that while this method will disable the alarm, the electric locks will still function, and the alarm can still be set. However, the car will lose its ability to honk the horn, flash the lights, and lock out the starter.
Additionally, some models of the Golf MK4 may have the alarm system connected to the bonnet latch. In these cases, you can follow the wires from the bonnet latch and disconnect the connector to the alarm system. However, this method may not always work, and disconnecting the negative battery cable may be necessary.
Another option is to remove specific fuses to disable the alarm. The central locking and alarm are located in the same box, known as the "convenience unit," and removing certain fuses will disable the alarm while retaining central locking functionality.
UNC Wilmington Golf: A Division I Legacy
You may want to see also
Explore related products
Disabling the panic alarm
One common issue with the MK4 alarm is a faulty driver's door lock actuator, which can cause the alarm to sound randomly due to a false report that the door is open. This can be resolved by replacing the actuator, which typically costs around $25. Alternatively, you can try covering any corroded wires leading to the hatch with electrical tape, as this may also resolve the issue.
If you wish to disable the alarm without addressing the root cause, you can try the following methods:
- Remove the trim surround panel for the fuse block. Remove the two screws holding the fuse block, push it in, and manoeuvre it out of the way. You will see a black plastic box ("comfort module") with two connectors. Unplug the nearest connector, and the smaller of the two. There are retention latches on the plug that need to be squeezed together to remove it.
- Remove the blue 16-pin plug from the comfort module. This will disable the factory alarm, but it may also disable some other functions like electric windows and the dome light.
- Disconnect the battery. However, please note that the alarm likely has a backup battery, so this may not be effective.
- Remove the central locking fuse, as described by a user: "Unlock the car, open the door, close the door, will not self-lock."
Putters in Golf: Long Ones Legal?
You may want to see also
Explore related products
Removing the central locking fuse
To disable the central locking and alarm system on a Golf MK4, you will need to access the fuse box. The central locking and alarm are located in the same box, known as the "convenience unit" or "comfort module", situated under the dash to the right of the steering column, above the relay plate.
First, remove the trim surround panel for the fuse block. This is a snap-off/on piece. Next, remove the two screws holding the fuse block to the brackets, push it in, and manoeuvre it out of the way. You will then see a black plastic box with two connectors facing the back of the car. Unplug the nearest connector, the smaller of the two. There are retention latches on the top and bottom of the plug that need to be squeezed together to remove it.
Golf Buddy App: Setup for Success
You may want to see also
Explore related products
Replacing the VW alarm immobiliser
The VW alarm and immobiliser are separate systems in separate units controlled by separate parts of the key. The central locking and alarm are in the same box, called the convenience unit, located under the dash to the right of the steering column above the relay plate.
If you are looking to replace the VW alarm immobiliser, you can try the following:
- Check your key fob battery. A dead key fob battery is a common cause of immobiliser problems. Replace the battery and see if this fixes the problem.
- Try your spare key. If your car still won't start with your spare key, then the problem is likely with the immobiliser system itself.
- Reset the immobiliser. Some Volkswagen models have a procedure for resetting the immobiliser. Consult your owner's manual for instructions.
- If you have recently had your car serviced, check to make sure that the mechanic did not disconnect or damage any of the immobiliser system components.
- If you are locked out of your car, you can use the key in the hidden keyhole in your car door to gain access manually. Remove the plastic cover carefully to access the keyhole.
- If you have a spare key fob, try programming it to your car. This can sometimes fix immobiliser problems caused by a faulty key fob.
- Recognise what caused the issue. Battery disconnection could also trigger it; replacing or disconnecting car batteries could activate its alarm system and need a reset. Sometimes, wear and tear on the ignition system can lead to immobiliser issues, ranging from a broken ignition switch to updating software that affects its settings.
- Turn on the ignition. Insert the key into the ignition and turn it to "on" without starting your car yet to allow the immobiliser to recognise that the correct key has been used.
- Disconnect the battery. This can sometimes reset the immobiliser, but it's not a reliable solution.
- Remove the positive and negative battery terminals, touch them together for 30 seconds, and that will reset the ecm/immobiliser.
If you have tried all of the above and your car still won't start, you will need to take it to a Volkswagen specialist for diagnosis and repair.
Frisbee Golf: Sport or Leisure Activity?
You may want to see also
Frequently asked questions
The central locking and alarm are in the same box, known as the "convenience unit", located under the dash to the right of the steering column. Removing the two 15-amp fuses, known as S144 and S111, will shut down the alarm, central locking, and alarm horn.
One can disable the alarm by removing the blue 16-pin plug from the "comfort module". This will disable the factory alarm, but the car will still start and central locking will work. However, the electric windows and dome light will also be disabled.
The issue may be related to the driver's door lock actuator, which contains three micro-switches that indicate whether the door is open or closed. One of these switches may be sending a false report that the door is open.
