Ava Romero
There are several ways to install a front license plate on a Golf Mk7. Some methods involve using 3M double-sided tape, velcro straps, or drilling holes and using screws and brackets. One popular method is to use a CravenSpeed Platypus License Plate Mount, which involves removing the towing eye cover, installing a flange bolt, and adjusting the plate to accommodate parking sensors. Another option is the Legit Speed mount, which is easy to install and does not require drilling. Some users have also suggested using a zip tie to attach the plate to the lower grill, or simply leaving the front plate off altogether to improve the styling of the car.
| Characteristics | Values |
|---|---|
| Installation time | 15 minutes |
| Installation process | Locate the circular towing eye cover on the passenger side of the front bumper. Push on the left side of the cover to pop it out. Remove the cover by tugging lightly. Squeeze the end together to fit it through the slot. Keep the cover in a safe place. Install the 15mm flange bolt into the hex stud, leaving a gap bigger than the thickness of the back plate. Insert the bolt through the hole in the tab of the back plate. Slide the plate over so the bolt rests in the slot. Tighten the bolt with a 15mm socket. Install the 4 ¼-20 button head screws to attach the license plate to the back plate with an Allen wrench. |
| Installation tips | If your car has parking sensors, adjust the plate accordingly. |
| Installation kits | CravenSpeed Platypus License Plate Mount, Legit Speed, US Millworks, Rho-plate, VW671 |
Explore related products
![Heavy Duty Front License Plate Frame Compatible with Volkswagen Golf R and GTI2015-2017[Mk7], Rust Proof Tow Hook Car Plate Holder, License Replacement Bracket with Mounting Kit for Easy Installation](https://m.media-amazon.com/images/I/71uoZhdyU7L._AC_UL320_.jpg)
What You'll Learn
CravenSpeed Platypus License Plate Mount installation guide
Thank you for purchasing the CravenSpeed Platypus License Plate Mount. This product is made from high-grade materials and is guaranteed to be free from defects. Please note that this installation process is very easy and should take around 15 minutes.
Firstly, locate the circular towing eye cover on the passenger side of the front bumper. Push on the left side of the cover and it will pop out of the bumper. The cover has a little tail that keeps it attached to the bumper skin. Give it a light tug and it should come out of the slot. You may need to squeeze the end together to make it fit through. Keep the painted cover in a safe place in case you need to put it back in later.
The hex stud included with this kit should have the part number “HEX-B19R097” or “CRVW-0069-21,” engraved on it. If the one you received doesn’t match, send an email to [email protected] and we’ll get you set up with the correct kit. Now, install the black hex stud. It should have “HEX-Y20R067” engraved on the side. You’ll need a 7/8" socket for the stud, preferably a deep socket, or an extension. Once you’ve got it in, tighten it with a socket wrench.
Next, install the 15mm flange bolt into the end of the hex stud, leaving a gap between the flange and the end of the stud that is slightly bigger than the thickness of the back plate. Grab the back plate and insert the head of the bolt through the hole in the tab. Then, slide the plate over so that the bolt rests fully seated into the slot. Hand tighten the bolt to keep it in place. While holding the back plate level with one hand, use a 15mm socket to tighten the bolt securely with your other hand.
Finally, use the 4 stainless steel button head screws to attach your license plate to the back plate. You’ll need a 5/32” hex wrench for the screws. If your car has parking sensors, you may need to adjust the plate to accommodate them. It is helpful to have a second person help you with this step. To accommodate for parking sensors, the back plate is designed so that the angle of the plate in relation to the bumper can be adjusted. If you’d also like to use a license plate frame, we have 1/2" screws available.
Congratulations! Your CravenSpeed Platypus License Plate Mount is now installed. Please note that our Platypus License Plate Mounts can be easily removed, so only put it on when you need it. For example, if you are going through an automated non-touchless car wash, simply use the included quick-release wrench to pop your plate off to avoid any interference.
Golf Coverage: The Athletic's Comprehensive Guide
You may want to see also
Explore related products
![Front License Plate Holder Compatible with Volkswagen Golf R and GTI 2015-2017 [Mk7] Front Bumper Tow Hook License Plate Mounting Bracket Holder No Drill License Plate Frames Car Accessories Kit](https://m.media-amazon.com/images/I/71UJpNeGDVL._AC_UL320_.jpg)
Legit Speed installation
The Legit Speed installation process for the MK7 Golf-R Front License Plate Bracket is straightforward and can be completed in a few simple steps.
Firstly, gather the necessary tools and hardware. The bracket should come with all the required components, including instructions. Ensure you have the correct bracket for your specific MK7 model and year.
Next, carefully remove any existing license plate mounting hardware or covers. This may involve unscrewing bolts or popping off covers, being mindful of any parking sensors your car may have. Refer to your car's manual if needed.
Now, position the Legit Speed bracket in place. Line up the bracket with the designated mounting points on your MK7's bumper. The bracket should have designated slots or holes for attachment.
Using the provided hardware, securely fasten the bracket to the bumper. This typically involves using screws or bolts, ensuring they are tightened appropriately.
Finally, attach your license plate to the Legit Speed bracket. Utilize the provided screws or bolts, ensuring they are tightened securely. Adjust the angle of the license plate as needed to avoid triggering parking sensors.
The Legit Speed installation process for the MK7 Golf-R Front License Plate Bracket is now complete. You can refer to the provided instructions for additional details or troubleshooting steps. This process ensures a secure and aesthetically pleasing installation of your front license plate on your MK7 Golf-R.
Travis Kelce's Golf Game: Pro or Beginner?
You may want to see also
Explore related products
Rho Plate installation
The RHO-Plate V2 is a tow hook license plate relocator for the Volkswagen Golf. It is available for the Golf GTI (Mk7), Golf R (Mk7), Golf SportWagen and Alltrack (Mk7), and Golf GTI and Golf R (Mk7.5).
To install the RHO-Plate V2 on your Volkswagen Golf Mk7 or Mk7.5, you will need to follow these steps:
Firstly, locate the factory tow hook mounting location on your vehicle's bumper. This is typically found on the lower front bumper, near the center. Remove any existing screws or fasteners that are currently in place. The next step is to place the RHO-Plate against the bumper, lining up the mounting holes. Secure the RHO-Plate to the bumper using the provided hardware, making sure that it is firmly attached.
Now, you will need to attach the license plate to the RHO-Plate. Place the license plate onto the RHO-Plate, ensuring that it is centered and secure it in place using the provided screws or fasteners. You may need to drill new holes or adjust the existing ones on your license plate for a perfect fit.
Finally, you can now attach a tow hook to the RHO-Plate. This is an optional step, but if you wish to use a tow hook, simply screw it into the designated hole on the RHO-Plate. Test the stability of the tow hook by gently pulling on it to ensure it is secure.
Your Volkswagen Golf Mk7 or Mk7.5 will now have a stylish and secure license plate setup, with the added benefit of a tow hook option. Please consult your vehicle's manual or a professional for further guidance on tow hook usage.
Golf and Back Pain: Is There a Link?
You may want to see also
Explore related products
Using 3M double-sided tape
To use this method, you can follow these steps:
- Form the license plate to match the curve of the bumper: Bend the license plate to sit flush against the bumper, especially if it has a curved surface like the S550 front bumper. You can use a rolling pin to help you bend the plate and break the back of the embossed frame.
- Clean the surface: Ensure that the area where you will apply the tape is clean and free of debris.
- Apply 3M double-sided tape: Use outdoor-rated 3M tape, such as Scotch/3M outdoor mounting tape, or 3M's command line tape. Apply vertical and horizontal strips of tape to the sides and back of the license plate, ensuring that the tape is slightly thinner than the thickness of the license plate.
- Position the license plate: Line up the center marks of the license plate and bumper, and position the plate so that it sits just below the break line of the front bumper. This will prevent the plate from poking up and snagging on anything.
- Apply pressure: Use a towel to apply even pressure over the license plate, pressing it firmly onto the tape and the bumper.
While this method is convenient and reversible, it may not be as secure as using screws or bolts. If you live in an area with extreme weather conditions, the tape may not hold up well over time, and you may need to reapply it every six months or so.
Some users have reported success with this method, especially when forming the plate to match the curve of the bumper, while others have expressed concerns about the tape's ability to withstand high speeds or extreme temperatures.
Who Is GM Golf's Girlfriend?
You may want to see also
Explore related products
![No Drill License Plate Holder Compatible with Volkswagen Golf R and GTI 2015-2017 [Mk7] Front Tow Hook License Plate Mount Bumper Bracket Holder Car Tag Frame Adapter Accessories](https://m.media-amazon.com/images/I/71PfjBuIzbL._AC_UL320_.jpg)
Tow hook mounts
The installation of a front plate using tow hook mounts on a Golf MK7 is a straightforward process that can be completed in a short amount of time.
One option for tow hook mounts is the CravenSpeed Platypus License Plate Mount. The installation process for this product involves first locating the circular towing eye cover on the passenger side of the front bumper. By pushing on the left side of the cover, it can be removed from the bumper, although it will remain attached by a small tail. The next step is to install the 15mm flange bolt into the hex stud included with the kit, leaving a gap slightly larger than the thickness of the back plate. The back plate can then be inserted onto the bolt and slid over so that the bolt sits fully within the slot, before being tightened by hand. Finally, the license plate can be attached to the back plate using ¼-20 button head screws, with adjustments made to accommodate parking sensors if necessary.
Another option for tow hook mounts is the TrunkNets Inc Bumper Tow Hook License Plate Mount Bracket. This product is suitable for Volkswagen MK7 / Golf GTi models from 2015 to 2022, with a bracket size of 6" x 12" that fits US and Canadian license plates. The installation of this bracket does not require any drilling, as it attaches to the tow hook area of the vehicle, causing no damage to the bumper. The kit includes unique screw bolts, black screw caps, and a wrench, with the only additional tool required being a Phillips head screwdriver. The license tag holder can be adjusted and rotated to the preferred angle, allowing the license plate to lay flat without warping or bending.
There are also other tow hook license plate mount options available for the Golf MK7, including the iJDMTOY No Drill Front Bumper Tow Hook License Plate Mounting Bracket Adapter Kit, the JIAHCN New Front Tow Hook License Plate Bracket Holder, and the Dewhel Front Bumper Tow Hook License Plate Mount Bracket Holder Bolt On No-Drill Modification Tow Eye LP Holder. These products offer similar benefits of easy installation and adjustability without the need for drilling, and are compatible with various Volkswagen MK7 models.
Golf Memberships: Tax Benefits for Businesses
You may want to see also
Frequently asked questions
You can purchase a Legit Speed front license plate bracket for the Golf Mk7. Users have reported that it is easy to install and does not require any drilling.
There are several options for installing a front plate on your Golf Mk7. Some users have suggested using 3M double-sided tape, but others have warned that it does not stick well in hot and wet climates. Another option is to use velcro straps or a tow hook mount, which can be purchased on Amazon.
Yes, there are alternatives to drilling when installing a front plate on your Golf Mk7. One option is to use a Cravenspeed Platypus License Plate Mount, which can be installed by removing the towing eye cover on the passenger side of the front bumper and attaching the license plate mount with the provided hardware.
To install a front plate on your Golf Mk7, you will need a 15mm socket and a 5/32” Allen wrench.
To avoid triggering the parking sensors, you can adjust the angle of the plate in relation to the bumper. Test drive the car after making adjustments to ensure that the sensors are not being triggered.
